Immobiliser delete and removal

Name: JF Automotive
Address: Unit 31, Integra, Parkwood Industrial Estate, Bircholt Rd, Maidstone, Kent, ME15 9GQ, United Kingdom
Telephone: 01622 321500
Price range: $$-$$$

When an ECU fails or has to be replaced, the immobiliser can stop the car starting. On supported ECUs we can remove the immobiliser function from the engine ECU.

Get a price → Call 01622 321500

Done in our Maidstone, Kent workshop
4.8 from 2,200+ reviews
Full list of supported ECUs below

What it is and when it makes sense

The immobiliser stops the engine starting unless it recognises the key. It is an important security feature, but when an engine ECU fails or is swapped, the immobiliser can stop the car running even though nothing else is wrong, and the dealer answer is often a new, coded ECU.

On supported ECUs we can remove the immobiliser function from the engine ECU so a replacement or repaired unit will run. It is most often used for ECU swaps, engine conversions and competition cars.

Think carefully before removing it from a road car: it is a security feature, and your insurer will need to know.

Engine ECU on the bench connected to a programming tool

How it works

Three steps

Tell us the carSend your registration and what is going on. We check your ECU is supported and what the car actually needs.
We quoteYou get a clear price before any work is booked, with our honest view if a repair would be the better route.
Done in our workshopThe car comes to our Maidstone workshop. We read the ECU, make the change, write it back and check the car before it goes home.

Good to know

We only remove an immobiliser with proof of ownership. Bring the V5C logbook and photo ID, and we check them before any work starts. No proof, no work.

Any change to your car’s software is a modification, so tell your insurer. We always diagnose first, and if a repair is the better answer for your car, we will say so.

Get a price

Tell us about your car

Send your registration and we will come back with what we can do and a fixed price. No obligation.

Before you send, want our discount codes?
Occasional offers on tuning, parts and servicing. No spam, and you can unsubscribe in one click.

Got it. We will check your ECU and come back with what we can do and a fixed price.

If you know them, these help us get the quote right first time. Entirely optional.

Loading the form…

Our workshop

Real people, our own ramps and dyno

Every job is done at our workshop in Maidstone, by the same team who answer the phone.

Working under a McLaren on the ramp at JF Automotive in Maidstone

Reading and writing an ECU file at the JF Automotive workshop

Working on the brakes at JF Automotive in Maidstone

Meet the team →

COVERAGE

Vehicles and control modules we cover

Immobiliser delete and removal is proven on 251 recorded vehicle and control module combinations, across 22 car and van makes. Search for your make or your ECU number below. If yours is not listed it may still be possible, so it is worth asking.

Audi 36 control modules

Control module	What the job involves
BOSCH EDC15P	No extra steps
BOSCH EDC15V	No extra steps
BOSCH EDC15VM+	We need the EEPROM as well as the main file.
BOSCH EDC16CP34	We need the EEPROM as well as the main file.
BOSCH EDC16U1	We need the EEPROM as well as the main file.
BOSCH EDC16U34	We need the EEPROM as well as the main file.
BOSCH EDC17_C46	We need a full read including the EEPROM.
BOSCH EDC17_C54	We need a full read including the EEPROM.
BOSCH EDC17C64	We need a full read including the EEPROM.
BOSCH EDC17C74	We need a full read including the EEPROM.
BOSCH EDC17_U01	We need a full read including the EEPROM.
BOSCH EDC17_CP04	We need a full read including the EEPROM.
BOSCH EDC17_CP14	We need a full read including the EEPROM.
BOSCH EDC17_CP20	We need a full read including the EEPROM.
BOSCH EDC17_CP24	We need a full read including the EEPROM.
BOSCH EDC17_CP44	We need a full read including the EEPROM.
BOSCH EDC17_CP54	We need a full read including the EEPROM.
BOSCH ME3.2	We need the EEPROM as well as the main file.
BOSCH ME7.5	No extra steps
BOSCH MED9.1 New	The EEPROM has to be processed alongside the main file.
BOSCH MED9.1.1 New	The EEPROM has to be processed alongside the main file.
BOSCH MED9.1.2 New	The EEPROM has to be processed alongside the main file.
BOSCH MED9.5	We need the EEPROM as well as the main file.
BOSCH MED9.5.10	We need the EEPROM as well as the main file.
BOSCH MED17.1	We need a full read including the EEPROM.
BOSCH MED17.1.1	We need a full read including the EEPROM.
BOSCH MED17.1.27	We need a full read including the EEPROM. The MPC is written first and the EEPROM second. A bypass on the starter relay is sometimes needed.
BOSCH MED17.5	We need a full read including the EEPROM.
BOSCH MED17.5.1	We need a full read including the EEPROM.
BOSCH MED17.5.2	We need a full read including the EEPROM.
BOSCH MED17.5.5	We need a full read including the EEPROM.
BOSCH MED17.5.6	We need a full read including the EEPROM.
BOSCH MED17.5.20	We need a full read including the EEPROM. The MPC is written first and the EEPROM second. A bypass on the starter relay is sometimes needed.
BOSCH MED17.5.21	We need a full read including the EEPROM.
SIEMENS 5WKP4326	We need the EEPROM as well as the main file.
SIEMENS SIMOS 3.3A	No extra steps

BMW 16 control modules

Control module	What the job involves
BOSCH EDC17_CP02	We need a full read of the module, not an OBD read.
BOSCH EDC17_C06	We need a full read of the module, not an OBD read.
BOSCH EDC17_CP09	We need a full read of the module, not an OBD read.
BOSCH EDC17_C41	We need a full read of the module, not an OBD read.
BOSCH EDC17_CP45	We need a full read of the module, not an OBD read.
BOSCH EDC17_CP49	We need a full read of the module, not an OBD read.
BOSCH EDC17_C50	Now EEPROM can be processed.
BOSCH EDC17_C56	Now EEPROM can be processed.
BOSCH MED17.1.1	We need a full read of the module, not an OBD read.
BOSCH MEVD17.2	We need a full read including the EEPROM.
BOSCH MEVD17.2.5	We need a full read of the module, not an OBD read.
BOSCH MEVD17.2.6	We need a full read of the module, not an OBD read.
BOSCH MEVD17.2.8	We need a full read of the module, not an OBD read.
BOSCH MEVD17.2.9	We need a full read of the module, not an OBD read.
BOSCH MEVD17.2.G	We need a full read of the module, not an OBD read.
BOSCH MEVD17.2.H	We need a full read of the module, not an OBD read.

Chevrolet 2 control modules

Control module	What the job involves
BOSCH EDC16C39	The immobox must be unplugged.We need the EEPROM as well as the main file.
BOSCH EDC17_C59	We need a full read of the module, not an OBD read.

Citroen 12 control modules

Control module	What the job involves
BOSCH EDC15C2	No extra steps
BOSCH EDC16C3	We need the EEPROM as well as the main file.
BOSCH EDC16C0	No extra steps
BOSCH EDC16C34	The EEPROM has to be processed alongside the main file.
BOSCH EDC17_C10	We need a full read of the module, not an OBD read.
BOSCH EDC17C60	We need a full read of the module, not an OBD read.
BOSCH ME7.4.5	No extra steps
BOSCH MED17.4.2	We need a full read of the module, not an OBD read.
BOSCH MEV17.4	We need a full read of the module, not an OBD read.
CONTINENTAL SID807	A four digit PIN has to be entered in the modified area.
SIEMENS SID801	No extra steps
SIEMENS SID803A	We need the EEPROM as well as the main file. Supplied as a virgin file.

DS 5 control modules

Control module	What the job involves
BOSCH EDC17_C10	We need a full read of the module, not an OBD read.
BOSCH EDC17C60	We need a full read of the module, not an OBD read.
BOSCH MED17.4.2	We need a full read of the module, not an OBD read.
BOSCH MEV17.4	We need a full read of the module, not an OBD read.
CONTINENTAL SID807	A four digit PIN has to be entered in the modified area.

Fiat 20 control modules

Control module	What the job involves
BOSCH EDC15C2	File must be sent through ticket system.
BOSCH EDC15C7	The antenna coil must be unplugged.
BOSCH EDC16C34	No extra steps
BOSCH EDC16C39	No extra steps
BOSCH EDC17_C84	We need a full read of the module, not an OBD read.
DELPHI DCM3.5	EEPROM must be sent through ticket system.
MARELLI MJ8DFHW00A	No extra steps
MARELLI MJ8DFHW00P	No extra steps
MARELLI MJ8DFHW00T	No extra steps
MARELLI MJ8F3HW00A	No extra steps
MARELLI MJ8F3HW00B	No extra steps
MARELLI MJ8F3HW00D	No extra steps
MARELLI MJ8F3HW10C	No extra steps
MARELLI MJ8F3HW10L	No extra steps
MARELLI MJ8F3HW10P	No extra steps
MARELLI MJ8F3HW10W	No extra steps
MARELLI MJ8F3HW1FL	No extra steps
MARELLI MJ8F3HW1FP	No extra steps
MARELLI MJ8F3HW20P	No extra steps
MARELLI MJ8F3HW2FP	No extra steps

Honda 1 control module

Control module	What the job involves
KEIHIN 37805-R3A New	No extra steps

Hyundai 11 control modules

Control module	What the job involves
BOSCH EDC16C39	The Smartra immobiliser unit must be unplugged.We need the EEPROM as well as the main file.
BOSCH EDC17_C08	The Smartra immobiliser unit must be unplugged.We need a full read of the module, not an OBD read.
BOSCH EDC17_C57	No extra steps
BOSCH EDC17_CP14	We need a full read of the module, not an OBD read.
BOSCH M7.9.8 / KEFICO MG7.9.8	The Smartra immobiliser unit must be unplugged.
BOSCH ME17.9.11	We need a full read including the EEPROM.
BOSCH MED17.9.21.1	The Smartra immobiliser unit must be unplugged.We need a full read including the EEPROM.
BOSCH MED17.9.8	We need a full read of the module, not an OBD read.
BOSCH MEG17.9.2	We need a full read of the module, not an OBD read.
BOSCH MEG17.9.12	We need a full read of the module, not an OBD read.
DELPHI MT38	No extra steps

Kia 8 control modules

Control module	What the job involves
BOSCH EDC16C39	The Smartra immobiliser unit must be unplugged.We need the EEPROM as well as the main file.
BOSCH EDC17_C08	The Smartra immobiliser unit must be unplugged.We need a full read including the EEPROM.
BOSCH EDC17_C57	No extra steps
BOSCH EDC17_CP14	We need a full read including the EEPROM.
BOSCH M7.9.8 [KEFICO MG7.9.8]	The Smartra immobiliser unit must be unplugged.
BOSCH ME17.9.11	We need a full read including the EEPROM.
BOSCH MED17.9.8	We need a full read of the module, not an OBD read.
BOSCH MEG17.9.12	We need a full read of the module, not an OBD read.

Lamborghini 1 control module

Control module	What the job involves
BOSCH MED9.1.1	We need the EEPROM as well as the main file.

Mercedes 2 control modules

Control module	What the job involves
BOSCH EDC17C66	We need a full read of the module, not an OBD read.
BOSCH MED17.7.2	We need a full read of the module, not an OBD read.

Mini 2 control modules

Control module	What the job involves
BOSCH EDC17_C41	We need a full read of the module, not an OBD read.
BOSCH MEVD17.2.X	We need a full read of the module, not an OBD read.

Nissan 1 control module

Control module	What the job involves
BOSCH EDC17_C45	We need a full read of the module, not an OBD read.

Opel 5 control modules

Control module	What the job involves
BOSCH EDC17_C18	We need a full read of the module, not an OBD read.
BOSCH EDC17_C19	We need a full read of the module, not an OBD read.
BOSCH EDC17_C59	We need a full read of the module, not an OBD read.
MARELLI MJ8F3HW1FP	No extra steps
MARELLI MJ8F3HW2FP	No extra steps

Peugeot 12 control modules

Control module	What the job involves
BOSCH EDC15C2	No extra steps
BOSCH EDC16C3	We need the EEPROM as well as the main file.
BOSCH EDC16C0	No extra steps
BOSCH EDC16C34	The EEPROM has to be processed alongside the main file.
BOSCH EDC17_C10	We need a full read of the module, not an OBD read.
BOSCH EDC17C60	We need a full read of the module, not an OBD read.
BOSCH ME7.4.5	No extra steps
BOSCH MED17.4.2	We need a full read of the module, not an OBD read.
BOSCH MEV17.4	We need a full read of the module, not an OBD read.
CONTINENTAL SID807	A four digit PIN has to be entered in the modified area.
SIEMENS SID801	No extra steps
SIEMENS SID803A	We need the EEPROM as well as the main file. Supplied as a virgin file.

Porsche 1 control module

Control module	What the job involves
BOSCH EDC17_CP44	We need the EEPROM as well as the main file.

Renault 1 control module

Control module	What the job involves
SAGEM S3000	Supplied as a virgin file.

Seat 33 control modules

Control module	What the job involves
BOSCH EDC15P	No extra steps
BOSCH EDC15V	No extra steps
BOSCH EDC15VM+	We need the EEPROM as well as the main file.
BOSCH EDC16CP34	We need the EEPROM as well as the main file.
BOSCH EDC16U1	We need the EEPROM as well as the main file.
BOSCH EDC16U34	We need the EEPROM as well as the main file.
BOSCH EDC17_C46	We need a full read including the EEPROM.
BOSCH EDC17_C54	We need a full read including the EEPROM.
BOSCH EDC17C64	We need a full read including the EEPROM.
BOSCH EDC17C74	We need a full read including the EEPROM.
BOSCH EDC17_U01	We need a full read including the EEPROM.
BOSCH EDC17_CP04	We need a full read including the EEPROM.
BOSCH EDC17_CP14	We need a full read including the EEPROM.
BOSCH EDC17_CP20	We need a full read including the EEPROM.
BOSCH ME3.2	We need the EEPROM as well as the main file.
BOSCH ME7.5	No extra steps
BOSCH MED9.1 New	The EEPROM has to be processed alongside the main file.
BOSCH MED9.1.1 New	The EEPROM has to be processed alongside the main file.
BOSCH MED9.1.2 New	The EEPROM has to be processed alongside the main file.
BOSCH MED9.5	We need the EEPROM as well as the main file.
BOSCH MED9.5.10	We need the EEPROM as well as the main file.
BOSCH MED17.1	We need a full read including the EEPROM.
BOSCH MED17.1.1	We need a full read including the EEPROM.
BOSCH MED17.1.27	We need a full read including the EEPROM. The MPC is written first and the EEPROM second. A bypass on the starter relay is sometimes needed.
BOSCH MED17.5	We need a full read including the EEPROM.
BOSCH MED17.5.1	We need a full read including the EEPROM.
BOSCH MED17.5.2	We need a full read including the EEPROM.
BOSCH MED17.5.5	We need a full read including the EEPROM.
BOSCH MED17.5.6	We need a full read including the EEPROM.
BOSCH MED17.5.20	We need a full read including the EEPROM. The MPC is written first and the EEPROM second. A bypass on the starter relay is sometimes needed.
BOSCH MED17.5.21	We need a full read including the EEPROM.
SIEMENS 5WKP4326	We need the EEPROM as well as the main file.
SIEMENS SIMOS 3.3A	No extra steps

Skoda 33 control modules

Control module	What the job involves
BOSCH EDC15P	No extra steps
BOSCH EDC15V	No extra steps
BOSCH EDC15VM+	We need the EEPROM as well as the main file.
BOSCH EDC16CP34	We need the EEPROM as well as the main file.
BOSCH EDC16U1	We need the EEPROM as well as the main file.
BOSCH EDC16U34	We need the EEPROM as well as the main file.
BOSCH EDC17_C46	We need a full read including the EEPROM.
BOSCH EDC17_C54	We need a full read including the EEPROM.
BOSCH EDC17C64	We need a full read including the EEPROM.
BOSCH EDC17C74	We need a full read including the EEPROM.
BOSCH EDC17_U01	We need a full read including the EEPROM.
BOSCH EDC17_CP04	We need a full read including the EEPROM.
BOSCH EDC17_CP14	We need a full read including the EEPROM.
BOSCH EDC17_CP20	We need a full read including the EEPROM.
BOSCH ME3.2	We need the EEPROM as well as the main file.
BOSCH ME7.5	No extra steps
BOSCH MED9.1 New	The EEPROM has to be processed alongside the main file.
BOSCH MED9.1.1 New	The EEPROM has to be processed alongside the main file.
BOSCH MED9.1.2 New	The EEPROM has to be processed alongside the main file.
BOSCH MED9.5	We need the EEPROM as well as the main file.
BOSCH MED9.5.10	We need the EEPROM as well as the main file.
BOSCH MED17.1	We need a full read including the EEPROM.
BOSCH MED17.1.1	We need a full read including the EEPROM.
BOSCH MED17.1.27	We need a full read including the EEPROM. The MPC is written first and the EEPROM second. A bypass on the starter relay is sometimes needed.
BOSCH MED17.5	We need a full read including the EEPROM.
BOSCH MED17.5.1	We need a full read including the EEPROM.
BOSCH MED17.5.2	We need a full read including the EEPROM.
BOSCH MED17.5.5	We need a full read including the EEPROM.
BOSCH MED17.5.6	We need a full read including the EEPROM.
BOSCH MED17.5.20	We need a full read including the EEPROM. The MPC is written first and the EEPROM second. A bypass on the starter relay is sometimes needed.
BOSCH MED17.5.21	We need a full read including the EEPROM.
SIEMENS 5WKP4326	We need the EEPROM as well as the main file.
SIEMENS SIMOS 3.3A	No extra steps

Suzuki 2 control modules

Control module	What the job involves
BOSCH ME17.8	We need a full read of the module, not an OBD read.
BOSCH ME17.9.64	We need a full read of the module, not an OBD read.

Volvo 1 control module

Control module	What the job involves
BOSCH EDC17_CP22	We need a full read including the EEPROM.

VW 36 control modules

Control module	What the job involves
BOSCH EDC15P	No extra steps
BOSCH EDC15V	No extra steps
BOSCH EDC15VM+	We need the EEPROM as well as the main file.
BOSCH EDC16CP34	We need the EEPROM as well as the main file.
BOSCH EDC16U1	We need the EEPROM as well as the main file.
BOSCH EDC16U34	We need the EEPROM as well as the main file.
BOSCH EDC17_U01	We need a full read including the EEPROM.
BOSCH EDC17_CP04	We need a full read including the EEPROM.
BOSCH EDC17_CP14	We need a full read including the EEPROM.
BOSCH EDC17_CP20	We need a full read including the EEPROM.
BOSCH EDC17_CP24	We need a full read including the EEPROM.
BOSCH EDC17_CP44	We need a full read including the EEPROM.
BOSCH EDC17_C46	We need a full read including the EEPROM.
BOSCH EDC17_C54	We need a full read including the EEPROM.
BOSCH EDC17_CP54	We need a full read including the EEPROM.
BOSCH EDC17C64	We need a full read including the EEPROM.
BOSCH EDC17C74	We need a full read including the EEPROM.
BOSCH ME3.2	We need the EEPROM as well as the main file.
BOSCH ME7.5	No extra steps
BOSCH MED9.1 New	The EEPROM has to be processed alongside the main file.
BOSCH MED9.1.1 New	The EEPROM has to be processed alongside the main file.
BOSCH MED9.1.2 New	The EEPROM has to be processed alongside the main file.
BOSCH MED9.5	We need the EEPROM as well as the main file.
BOSCH MED9.5.10	We need the EEPROM as well as the main file.
BOSCH MED17.1	We need a full read including the EEPROM.
BOSCH MED17.1.1	We need a full read including the EEPROM.
BOSCH MED17.1.27	We need a full read including the EEPROM. The MPC is written first and the EEPROM second. A bypass on the starter relay is sometimes needed.
BOSCH MED17.5	We need a full read including the EEPROM.
BOSCH MED17.5.1	We need a full read including the EEPROM.
BOSCH MED17.5.2	We need a full read including the EEPROM.
BOSCH MED17.5.5	We need a full read including the EEPROM.
BOSCH MED17.5.6	We need a full read including the EEPROM.
BOSCH MED17.5.20	We need a full read including the EEPROM. The MPC is written first and the EEPROM second. A bypass on the starter relay is sometimes needed.
BOSCH MED17.5.21	We need a full read including the EEPROM.
SIEMENS 5WKP4326	We need the EEPROM as well as the main file.
SIEMENS SIMOS 3.3A	No extra steps

Faw 1 control module

Control module	What the job involves
BOSCH ME17.8.8	We need a full read of the module, not an OBD read.

Hako 1 control module

Control module	What the job involves
BOSCH EDC17_CP20	We need a full read of the module, not an OBD read.

Holden 1 control module

Control module	What the job involves
BOSCH EDC16C39	No extra steps

Isuzu 1 control module

Control module	What the job involves
TRANSTRON 4JJ1 New	Need to cut wire #68 on ECU.

Iveco 2 control modules

Control module	What the job involves
BOSCH EDC16C8	EEPROM must be sent through ticket system.
BOSCH EDC17C49	We need a full read of the module, not an OBD read.

JMC 1 control module

Control module	What the job involves
BOSCH EDC17_C63	We need a full read of the module, not an OBD read.

Lada 1 control module

Control module	What the job involves
BOSCH ME17.9.7	We need a full read of the module, not an OBD read.

Lancia 1 control module

Control module	What the job involves
MARELLI MJ8DFHW00T	We need a full read of the module, not an OBD read.

Mahindra 1 control module

Control module	What the job involves
BOSCH EDC17_C55	We need a full read of the module, not an OBD read.

HOW TO READ THIS

Each row is a control module we have a working solution for. The note tells you what typically also has to happen on the car, because where a part has to be unplugged that is mechanical work on the vehicle, not something a file alone can do.

We have more than one route to most of these jobs, so the requirements on your car are confirmed when we look at it rather than taken from this table. Treat the notes as what to expect, not as a fixed instruction.

Marked New means the solution is recent, so we check those individually before quoting.

Check my vehicle

Read the full immobiliser delete and removal guide in our Help Centre →

Reviews

What customers say

Fantastic service. Customer service was bang on and so was the workmanship. Had someone come out and fit a ghost pro immobilizer on my SVR. I was showed how to use everything afterwards and you couldn’t even tell any works had been done as the car was left spotless on…

Sean Mac

The Ghost Immobiliser was fitted in 1hr 40. On return, James gave very good instruction on how it worked - he sat in the passenger seat talking us through, was very patient, making sure we understood it all.

KathyB SEAT

Great service from the start, good communication throughout, and a great price for the remapping package. Will definitely be coming back with my other vehicles.

Consumer

Common questions

Will my car still be secure?

The engine ECU will no longer check the key, so the car is less secure. If that matters, ask us about adding a separate immobiliser such as an Autowatch Ghost.

Do I need to tell my insurer?

Yes. It changes the car's security, so your insurer needs to know.

Do you need proof of ownership?

Yes, always. Bring the V5C logbook and photo ID. We will not remove an immobiliser without them.

Which ECUs can you do?

The full list is below, or send us your registration and we will check.

More ECU services

Other software work we do

DPF delete and removal EGR delete and removal GPF delete and removal Lambda O2 delete and removal Swirl flap delete and removal MAF delete and removal TVA delete and removal Speed limiter delete and removal Start-stop disable DTC delete and removal AdBlue delete and repair ECU remapping
